S-ONE SS304 Stainless Steel Pipes & Fittings

Reference:

S-ONE Stainless Steel is made using an iron alloy that conforms to SS304 standards, which contains approximately 18% chromium and 8% nickel.

S-ONE SS304 Stainless Steel is rust-free and corrosion-resistant.

Some applications of the stainless steel pipes & fittings include transportation of potable water at low and high temperatures, transfer of fluids in HVAC-R systems, and piping in general chemical equipment.

Read more
Description

Dimensions:
Pipes: All pipes are of 5.8m length
Sizes (OD): 15mm to 108mm

Fittings: Pressfit fittings are all “M Profile
Variants: Elbows & Threaded Elbows, Threaded Adaptors, Couplings, Threaded Tees

For more information, do kindly contact our service staff.


Technical Data:

Property

Value / Assessment

Special Remarks / Standard

Normal Operating

Temperature

­20°C to + 120°C

EPDM O­-Ring inside fitting

Normal Operating Pressure

16 BAR (232 PSI)

Tested to 40/50 BAR

Chemical Composition

Passed Test

AISI Grade SS304

Pipe Hydrostatic Internal Test

Passed 50 BAR Pressure

BS:EN 10312 : 2002

Pipe Metal Toxicity Test for

drinking water

Passed Test

AS/NZS 4020 : 2018

Leak Tightness under

Hydrostatic Pressure &

Resistance to separating Test

No Leakage to Joints.


Max Axial Movement < 1mm.

BS:EN 1254­2 : 1998

Pressure Cyclic @ 95°C,

2MPa for no less than 50,000

cycles, & Resistance to

separating Test

No leaks or failure in Joints.


Pipe did not separate from

fittings.

AS 3688 : 2006

'Non­metallic product' Water

Consumption Safety Test

Passed Test

EPDM / SS 375 : 2015

Read more
